蛋白質設施
蛋白質養晶
委員會成員
位置
314室
管理者
黃開發 huangkf@gate.sinica.edu.tw +886-2-27855696,3090
施惠玲 mbce0326@hotmail.com +886-2-27855696,3140
簡介

本設施提供本所研究人員進行蛋白質及其他生物大分子快速晶體篩選服務,並支援晶體測試、X-光繞射數據收集及晶體結構解析等技術,及相關實驗諮詢和技術研發。設施主要儀器有自動點晶儀(Phoenix RE, RIGAKU)、自動分樣系統(Scorpion, ARI)、蛋白質X-光繞射儀(The protein X-ray diffraction system FR-E+ & R-AXIS HTC, RIGAKU)、自動晶體觀察系統(Crystal imaging system, Minstrel DT UV)、晶體培養箱及冷房。
服務收費      ⦁養晶室送件規則

1. 自動點晶儀 (RIGAKU Phoenix/RE crystallization robot) 型號: RIGAKU Phoenix/RE

本自動點晶儀具有快速分注蛋白質樣品之微量針頭同時以96隻針頭快速分注養晶條件,搭配依據多年經驗選擇之多種養晶條件,可快速設置微量蛋白質點晶盤,並得到晶體供後續結構解析。


請洽管理者
2. 晶體照相系統 (Minstrel™自動蛋白質晶體觀察及儲存系統) 型號: Minstrel™ DT UV

此晶體照相系統為一紫外光與可見光之晶體影像及蛋白質晶體觀察系統,可得到微小晶體之高解析度影像.可自動得到晶體影像同時與養晶條件連結,以利後續微調.其透過紫外光源所得到之影像則可協助判斷是否為蛋白質晶體。


請洽管理者
3. 蛋白質晶體X光繞射儀 (The protein X-ray diffraction system FR-E+ & R-AXIS HTC) 位置: 506室

The FR-E+ SuperBright (Rigaku) is an extremely intense home laboratory X-ray source, providing brightness exceeding some 2nd generation bending magnet synchrotron beamlines. With unrivalled intensities of 1.6 x1011 X-rays/mm2/sec, the generator produces twice the flux of the closest competitive instrument. This 2X advantage is made by advances in anode cooling technology. Ideal for rapid screening of samples and for collection of the highest quality data for in-house structure determination, the FR-E+ SuperBright provides the flux you need. On the other hand, the R-AXIS HTC is a design of unique three imaging-plate (IP) detector, allowing for simultaneous expose, erase, and readout operations during X-ray data collection. This means that the duty cycle is limited only by the speed of the IP transport from one position to the next, making the detector highly efficient for screening samples or for experiments with brief exposure times.


請洽管理者
4. 自動配藥機 (Scorpion Screen Builder)

Scorpion 是一款高速單通道pipettor,這款功能多樣的Scorpion可執行任何使用手持式pipettor執行的操作,且具有自動分注器的速度,可靠性和精確度。


請洽管理者
5. Leica M205C顯微鏡 (Leica M205C microscope)

可在同一視野下取得偏光和白光影像,影像放大倍率可到320倍,有明視野、簡易暗視野兩種照明方式,提供蛋白質結晶觀察高品質影像使用。搭配一台Canon數位相機,方便影像擷取。


現場登記
6. 實體顯微鏡 (Leica MZ16 microscope)

可在同一視野下取得偏光和白光影像,影像放大倍率可到160倍,有明視野、簡易暗視野兩種照明方式,提供蛋白質結晶觀察高品質影像使用。搭配一台Canon數位相機,方便影像擷取。


現場登記
7. Leica MZ95顯微鏡 (Leica MZ95 microscope)

可在同一視野下取得偏光和白光影像,影像放大倍率可到60倍,有明視野、簡易暗視野兩種照明方式,提供蛋白質結晶觀察高品質影像使用。搭配一台Canon數位相機,方便影像擷取。


現場登記
8. 儲存蛋白質結晶盤恆溫箱 (Storage crystal plate incubator)

恆溫箱體積小不佔空間,溫控4-40℃之間,溫控穩定與接近零震動,非常適合存放蛋白質結晶盤。


請洽管理者
9. 自動點晶儀 (Phoenix/RE crystallization robot) 型號: Phoenix/RE

本自動點晶儀具有快速分注蛋白質樣品之微量針頭同時以96隻針頭快速分注養晶條件,搭配依據多年經驗選擇之多種養晶條件,可快速設置微量蛋白質點晶盤,並得到晶體供後續結構解析。


請洽管理者
